Low Profile 20 Ton Air Operated Hydraulic Bottle Jack

Low profile 20 ton air operated bottle jack is designed for fast lifting and convenient servicing of vehicles.
Reasonable structure, easy operation, safe and reliable use.
Operates manually or with air.
Safety overload system prevents jack from being used beyond its rated capacity.
Packing: neutral color box
Sales Model: Wholesale
  • OA-20B
  • FORZA
  • 8425
Availability:
Quantity:
Low profile 20 ton air operated hydraulic bottle jack's air operation reduces operator fatigue and speeds up garage work.

The small and efficient air motor is designed to withstand dirt, sand and other outside elements

Light-weight which makes it excellent for mobile use.

Chrome plated ram which eliminates rusting.

Manufactured with an over-load by pass system which prevents the jack from going over its capacity.

Designed with a filter which helps keep dirt and other grime out of the cylinder.

Designed to operate with air or with manual handle.

Swivel on air hose allows for use in any direction.

Model number  OA-20B

Capacity

20 ton

Min.Height

210mm

Max. Height

390mm

Adjust Height

80mm

Lifting.H.

100mm

N.W.

14kg

G.W.

15kg

Qty/Ctn

1pc

Package size

260mmX220mmX230mm

Packing

neutral color box or customized color box.

MOQ

50 pcs

Air Operated Hydraulic Bottle Jack
