Hydraulic vehicle positioning jack 1500 Lbs is applicable to parking lot, trailer company, auto exhibition hall, garage, auto collector and museum, traffic management department, etc.
Place the tire in the middle of the drum, otherwise the stop arm may touch the side of the tire when the shifter tightens.
In order to prevent the pedal from deviating, first press the pedal with the right hand to the position close to the drum and tire width.
Continuous and uniform pedal to ensure that the drum can rotate smoothly to lift the wheel.
When removing the vehicle, the safety pin should be pulled out first to release the hydraulic valve.
Model number | OX-1500C |
Capacity | 1500 lbs |
Specification | 12" aluminium roller length, 4" PU casters |
Adjusting range between rollers | 345mm-620mm |
Qty/color box | 2pcs |
N.W. | 36kg |
G.W. | 38kg |
Package size | 880mmx620mmx220mm |
Packing way | neutral color box or customized color box. |
MOQ | 50 pcs |
Qty/color box | 1pc |
N.W. | 18kg |
G.W. | 20kg |
Package size | 680mmx620mmx220mm |
MOQ | 30 pcs |
Loading | Ningbo port or Shanghai port |
Delivery time | 25days-30days |
