2 Stage 1 Ton High Lift Hydraulic Transmission Jack

1 ton high lift hydraulic transmission jack is two-stage chrome hydraulic ram for bigger range.
Smooth hydraulic lift and descent. Foot pedal pump and release.
Sales Model: Wholesales
Packing: plywood box
Paint Color: Optional
  • OM-168

  • FORZA

  • 842

Availability:
Quantity:

1 Ton High Lift Hydraulic Transmission Jack is used in most cars transmission, engine parts, such as maintenance detection applications, double lifting section order, provide higher lifting height, head tray angle adjustment, the precision lead screw and nut with ball bearing, large tray Angle adjustment and energy foot pedal extended operation, easy operation foot type pressure relief valve design, more convenient unloading, security universal wheel with special material coated, move more smoothly.

Model number

OM-168

Capacity

1 ton

Min.H.

≤875 mm

Max.H.

≥1800mm

N.W.

75kg

G.W.

85kg

Qty/Ctn1pc

Package   size (mm)

560*370*880

Packing

plywood box

Color

Optional

MOQ

10pcs

Place of Original

Zhejiang, China

Loading Port

Ningbo or Shanghai port

Delivery time

25days-30days

MOQ

10pcs
